JIS G3302 Galvanized steel coil gi coil
JIS G3302 Galvanized steel coil
Width: 750-1250mm
Coating Mass: 20g-400g/m2
Surface Structure: Zero Spangle, Regular Spangle, Minimized Spangle
Surface Treatment: Chromated/ non-Chromated, Oiled/ non-Oiled
Coil inner diameter: 508mm or 610mm
Coating Mass: 20g-400g/m2
Surface Structure: Zero Spangle, Regular Spangle, Minimized Spangle
Surface Treatment: Chromated/ non-Chromated, Oiled/ non-Oiled
Coil inner diameter: 508mm or 610mm
Quantity
JIS G 3302 is a Japanese material standard for hot dipped galvanized steel coil. This standard applies to steel plates and steel strips (hereinafter referred to as steel strips and steel strips) that are hot-dipped galvanized on both sides in a plating solution containing more than 97% zinc (usually less than 0.30% aluminum).
Looking for a reliable supplier of JIS G3302 galvanized steel coils? Look no further than our top-quality products!
Specification
Example Size
Based on Hot-roll Sheet:
Grade | Nominal Thickness(mm) | Application |
SGHC | 1.60 ~ 6.00 | General Purpose |
SGH340 | Structural purposes | |
SGH400 | ||
SGH440 | ||
SGH490 | ||
SGH540 |
Based on Cold-roll Sheet:
| Grade | Nominal Thickness | Application |
| SGCC | 0.25 ~ 3.2 | General Purpose |
| SGCH | 0.11 ~ 1.0 | General Hard Use |
| SGCD1 | 0.40 ~ 2.3 | Stamping uses class 1 |
| SGCD2 | Stamping use class 2 | |
| SGCD3 | 0.60 ~ 2.3 | Stamping use class 3 |
| SGC340 | 0.25 ~ 3.2 | Structural purposes |
