ASTM A106 Seamless Steel Pipe Hot Rolled Tube
ASTM A106 smls tube, seamless steel pipeline
Certification: API
Standard: ASTM A106
Grade: Gr.B
Out Diameter: 1/2" - 24" ( DN15 - DN600)
Thickness: 2.24-59.54mm
Length: 6M/ 12M or Customized
Ends: Plain/ Bevel/ Threaded/ Grooved
Usage: Water transfer pipes/ Oil pipes and Gas pipes
Surface: Bare/ Black/ Varnish/ Oiled/ Galvanized/ 3PE, etc
Standard: ASTM A106
Grade: Gr.B
Out Diameter: 1/2" - 24" ( DN15 - DN600)
Thickness: 2.24-59.54mm
Length: 6M/ 12M or Customized
Ends: Plain/ Bevel/ Threaded/ Grooved
Usage: Water transfer pipes/ Oil pipes and Gas pipes
Surface: Bare/ Black/ Varnish/ Oiled/ Galvanized/ 3PE, etc
Quantity
ASTM A106 Gr.B Carbon Seamless Steel Tubes
Looking for a reliable ASTM A106 seamless steel pipe / smls tube manufacturer? Our hot rolled seamless pipe come with high-quality finishing, excellent durability, and unparalleled strength.
ASTM A106/ASME SA106 seamless steel pipeline is a carbon steel pipe manufactured by hot rolling. A106 seamless tube is particularly suitable where the fluid being conveyed is of high temperature or pressure (or both). Astm 106 seamless pipe can be used in high temperature applications (up to 750 degrees Fahrenheit).
It is used not only for piping systems in different industries, such as the transport of oil and gas, water and mineral slurries, but also in boilers, buildings, structures and other applications.
ASTM A106 seamless steel pipe is generally used in carbon steel, where Grade B pipe is equivalent to ASTM A53 Grade B and API 5L Grade B in terms of chemical position and mechanical properties.
Example Size
Note: Some of the main specifications are shown below, please contact us for more details.
Designator NPS | Designator DN | Outside Diameter | Wall Thickness | Weight Class | No. Schedule | Test Pressure, psi | |
mm | mm | Grade A | Grade B | ||||
1/2" | 15 | 21.3 | 2.77 | STD | 40 | 4.8 | 4.8 |
3.73 | XS | 80 | 5.9 | 5.9 | |||
4.78 | - | 160 | 6.2 | 6.2 | |||
7.47 | XXS | - | 6.9 | 6.9 | |||
6" | 150 | 168.3 | 4.78 | - | - | 7.0 | 8.2 |
5.56 | - | - | 8.2 | 9.6 | |||
6.35 | - | - | 9.4 | 10.9 | |||
7.11 | STD | 40 | 10.5 | 13.0 | |||
7.92 | - | - | 11.7 | 13.7 | |||
8.74 | - | - | 12.9 | 15.0 | |||
9.52 | - | - | 14.1 | 16.4 | |||
10.97 | XS | 80 | 16.2 | 18.9 | |||
Seamless Steel Pipe Manufacturing Process
Hot-rolled seamless steel tubes are one of the ways in which seamless steel tubes are produced, and are manufactured by the hot-rolling technique, which, as the name suggests, rolls at a high temperature, so that there is little resistance to deformation and large deformations can be achieved.
In contrast to cold rolling, hot-rolled seamless steel tubes are seamless steel tubes rolled above the recrystallisation temperature, whereas cold rolling is done at room temperature. The hot rolling process is usually used on larger diameter seamless steel tubes (above 38 mm). Smaller diameters of seamless steel tubes can be cold rolled or cold drawn.
